Aramid twill fabric

consisting of 200 gr/m'2, 75% m-Aramid, 23% p-Aramid, 2% Carbon.

Inherent flame retardant fabric

for firefighters.

Flame resistant (Flame retardant) fabric with EN ISO 11612 certification.

Antistatic (EN 1149-5)

Technical Parameters

Fiber	75% m-Aramid (m-AR) 23% p-Aramid (p-AR) 2% Carbon(CF)	EN ISO 2076
Yarn	Warp:30/2Ne; Weft:30/2Ne	EN ISO 2060
Weight	200 ±5 gr/m2	EN ISO 3081
Width	1600 ±20 mm	EN ISO 3932
Tensile Strength	Warp>1500N; Weft>1000N	EN ISO 13934-1
Tear Strength	Warp>70N ; Weft>60N	EN ISO 13937-2
Dimensional Change	-3% < Length < +3% ; -3% < Width < +3%	EN ISO 5077
Rubbing Fastness	4-5	EN ISO 105 X12
Perspiration Fastness	4-5	EN ISO 105 E04
Washing Fastness	4-5	EN ISO 105 C06
Dry Cleaning Fastness	4-5	EN ISO 105 D01
Hypochlorite Fastness	4-5	EN ISO 105 N01
Peroxide Fastness	4-5	EN ISO 105 N02
Hot Press Fastness	4-5	EN ISO 105 X11
Light Fastness	4-5	EN ISO 105 B02
Perspiration Light Fast.	4-5	EN ISO 105 B07
pH	6.0	EN ISO 3071
Azo Test	No Azo Colorants.	EN ISO 14362-1
Application	Firefighters Costumes
Quality Management	Done	ISO 9001
Flame and Heat Protection	Yes	EN ISO 11612
Antistatic	Yes	EN ISO 1149-5
Arc Protection	Class 1 (4kA)	EN ISO 61482-1-2
ATPV	> 12 cal/cm2	EN ISO 61482-1-1
Chemical Resistant	Yes	EN ISO 13034
Firefighters	Yes	EN ISO 469

Technical Documents
>> Aramid D3 200 Data Sheet

Certificates

Applications

Functions

Care Instructions

Colors and Article Numbers

	Orange	PP-24644	- STANDARD -	Aramid D3 200-4848
	Dark Green	PP-65457	- STANDARD -	Aramid D3 200-4849
	Red	PP-33921	- STANDARD -	Aramid D3 200-4850
	Dark Blue	PP-58627	- STANDARD -	Aramid D3 200-4851
	Black	PP-96036	- STANDARD -	Aramid D3 200-4852
	Navy	PP-58628	- STANDARD -	Aramid D3 200-4853
	Grey	PP-96034	- STANDARD -	Aramid D3 200-4854
	Dark Navy	PP-58625	- STANDARD -	Aramid D3 200-4855
