Protection Technical Textiles


High visible, waterproof, flame retardant, antistatic, chemical resistant workwear fabrics.

Protection Technical Textiles
Ar Wo Wear  T20 Flame+Arc Pro
260 gr/m2, 79% Cotton 20% Polyester 1% Carbon, VAT Dyed, Flame Retardant (100 Wash Resistant), Antistatic, 3/1S Twill Fabric
Flame Retardant Antistatic Cotton Fabrics

ArWoWear T20 Flame Arc Pro is light weight 260 gr/m', 79% Cotton %20 Polyester 1% Carbon, vat dyed, flame retardant, antistatic workwear fabric.


It has flame retardant function with EN ISO 11612 and EN ISO 11611 certification.

Due to carbon fibers used on the back side of the fabric it has antistatic certification. (EN 1149-5)


Protection against thermal hazards of electrical arc. (EN 61482-1-2)


It is durable up to 100 washing.


Technical Parameters

Fiber 79% Cotton (CO) 20% Polyester 1% Carbon(CF) EN ISO 2076
Yarn Warp:30/2Ne ; Weft:30/2Ne EN ISO 2060
Weight 260 ±10 gr/m2 EN ISO 3081
Width 1600 ±20 mm EN ISO 3932
Tensile Strength Warp>1000N; Weft>800N EN ISO 13934-1
Tear Strength Warp>20N; Weft>15N EN ISO 13937-2
Dimensional Change -3% < Length < +3% ; -3% < Width < +3% EN ISO 5077
Rubbing Fastness 4-5 EN ISO 105 X12
Perspiration Fastness 4-5 EN ISO 105 E04
Washing Fastness 4-5 EN ISO 105 C06
Dry Cleaning Fastness 4-5 EN ISO 105 D01
Hypochlorite Fastness 4-5 EN ISO 105 N01
Peroxide Fastness 4-5 EN ISO 105 N02
Hot Press Fastness 4-5 EN ISO 105 X11
Light Fastness 6-7 EN ISO 105 B02
Perspiration Light Fast. 4-5 EN ISO 105 B07
pH 6.0 EN ISO 3071
Azo Test No Azo Colorants. EN ISO 14362-1
Application Flame Retardant Shirt
Quality Management Done ISO 9001
Flame and Heat Protection Yes EN ISO 11612
Welding Protection Yes EN ISO 11611
Antistatic Yes EN ISO 1149-5
Arc Protection Class 1 (4kA) EN ISO 61482-1-2
ATPV > 10 cal/cm2 EN ISO 61482-1-1


Technical Documents

>> ArWoWear T20 Flame+Arc Pro Data Sheet

Certificates

EN 1149-5 EN 1149-5

EN 1149-5 test report EN 1149-5 Test Report




Applications



Functions

Oeko Tex Standard 100

EN 11612 EN 11611 EN 1149 EN 61482




Care Instructions

60'C Machine Wash Chlorine Based Bleaching Can Be Tumble Dried On Low Heat Setting Maximum 150'C Warm Iron Suitable for Dry Cleaning



Colors and Article Numbers

  Yellow PTIND 25044 - STANDARD - ArWoWear T20 Flame+Arc Pro-4762
  Orange PTIND 34468 - STANDARD - ArWoWear T20 Flame+Arc Pro-4763
  Dark Green PTIND 66236 - STANDARD - ArWoWear T20 Flame+Arc Pro-4764
  Red PTIND 34470 - STANDARD - ArWoWear T20 Flame+Arc Pro-4765
  Dark Blue PTIND 59885 - STANDARD - ArWoWear T20 Flame+Arc Pro-4766
  Black PTIND 96677 - STANDARD - ArWoWear T20 Flame+Arc Pro-4767
  Navy PTIND 59887 - STANDARD - ArWoWear T20 Flame+Arc Pro-4768
  Grey PTIND 96679 - STANDARD - ArWoWear T20 Flame+Arc Pro-4769
  Dark Navy PTIND 59890 - STANDARD - ArWoWear T20 Flame+Arc Pro-4770
  Khaki PTIND 66238 - STANDARD - ArWoWear T20 Flame+Arc Pro-4771
